Hatco TOASTMAX TM3-5 Series User Manual

MODEL DESCRIPTION
Form No. TM3M_CN-1015
4
English
All Models
All TOASTMAX
®
Electric Conveyor Toasters are fast, reliable,
and versatile, toasting up to 460 bread or bun product per hour.
TOASTMAX toasters feature long lasting serpentine metal
sheathed heating elements, a permanently lubricated conveyor
motor, and three selector keys. Every unit is shipped with
25 mm (1") adjustable legs, a feed ramp, a removable crumb
tray, and a discharge chute.
TM3-5 Model
The TM3-5 model allows for toasting of bread products up to
38 mm (1-1/2") thick and 187 mm (7-3/8") wide. Capacity is up
to 230–280 slices per hour, depending on voltage.
TM3-5H Model
The TM3-5H model allows for toasting of bread products up to
76 mm (3") thick and 187 mm (7-3/8") wide. Capacity is up to
190–230 slices per hour, depending on voltage.
TM3-10 model
The TM3-10 model allows for toasting of bread products up to
38 mm (1-1/2") thick and 245 mm (9-5/8") wide. Capacity is up
to 390–460 slices per hour, depending on voltage.
TM3-10H model
The TM3-10H model allows for toasting of bread products up to
76 mm (3") thick and 245 mm (9-5/8") wide. Capacity is up to
290–350 slices per hour, depending on voltage.
TM3-5 and TM3-10H Models
COLOR
CONTROL
Knob
Feed
Ramp
Crumb
Tray
Discharge
Chute
Power
I/O (on/off)
Switch
COLOR
CONTROL
Knob
Feed
Ramp
Crumb
Tray
TM3-5
TM3-10H
Discharge
Chute
Power
I/O (on/off)
Switch
Selector
Keys
Selector
Keys
MODEL DESIGNATION
T M 3 - X X H
TOASTMAX
®
H = 76 mm (3") toast opening height
No Character = 54 mm (2-1/8") toast opening height
10 = Full-size (2 slice) toaster
5 = Half-size (1 slice) toaster
