Operation and use 2L41C, 2M41, 2M41Z
40
HATZ
Operator’s Manual
Overview
Numbering of the valves and cylinders from the fan side
1
2
3
4
1 2 3 4
5
6
7
8
Crank handle Attach the crank handle
1 Handle bar
2 Crank arm
3 Drive dog
4 Guide sleeve
