64 2420332370 E06.11 EN
Engine-powered articulated lifts, 12 - 26 m
D
- Operating principle
2.10 - RADIUS LIMITATION
For HA260PX
N.B.-:-THE PRESENCE OF THIS DEVICE DEPENDS ON THE MACHINE CONFIGURATION.
The radius limit indicator (orange) on the platform control box is a visual indicator.
• The radius limit indicator flashes to indicate that a controlled movement has occured to maintain the
machine within the stability limit. For example : The machine retracts the telescope as and when you
request the lowering of the boom. It is not possible to add other movements during these phases, for
safety reasons. Driving is forbidden in this zone.
• This indicator remains on when the operator requests a movement which would cause the platform to
leave the work area.
