Haussmann HLG034 - Page 38

gb
38
No. Description Qty. No. Description Qty.
1 Screw M5*10 1 43 Piston 1
2 Gasket 5 1 44 Piston pin 1
3 Starter pulley 1 45 Piston ring 2
4 Starter rope 1 46 Cylinder mat 1
5 Starter spring 1 47 Cylinder 1
6 Starter cover 1 48 Screw M5*20 4
7 Starter handle 1 49 Cylinder cover 1
8 Handle cover 1 50 Screw M5*25 1
9 Start complex 1 51 Top cover 1
10 Rubber 1 52 Spark plug 2
11 Fuel tank bracket 1 53 Spark plug cover 1
12 Screw M5*16 4 54 Rubber 1
13 Gasket 1 55 Mufer mat 1
14 Bolt M8*1 1 56 Mufer 1
15 Claw 1 57 Screw M5*12 1
16 Spring 1 58 Screw M5*55 2
17 Plate 1 59 Mufer cover 1
18 Ring 4 1 60 Oil inlet base gasket 1
19 Oil seal 12*22*7 2 61 Oil inlet base 1
20 Left crankcase 1 62 Carburetor mat 1
21 Crankcase mat 1 63 Carburetor 4
22 Bearing 6201 2 64 Throttle cable bracket 1
23 Crank shaft 1 65 Screw 1
24 Semi-circular key3*10* 1 66 Mounting bracket 4
25 Pin A4*10 4 67 Air cleaner base 1
26 Plate 1 68 Choke lever 1
27 Right crankcase 1 69 Screw M4*10 2
28 Screw M5*30 4 70 Air cleaner core 1
29 Flywheel 1 71 Air cleaner cover 2
30 Bolt M8 1 72 Cover screw 2
31 Ignition 1 73 Fuel tank tting 1
32 Screw M5*20 4 74 Oil inlet tube 1
33 Flameout wire 1 75 Oil cleaner 1
34 Gasket 10 1 76 Oil return tube 2
35 Clutch spring 1 77 Screw M5*16 2
36 Clutch block 2 78 Fuel tank 1
37 Lower gasket 10 1 79 Fuel tank cover complex 1
38 Screw 1 80 Fuel tank cover 1
39 Anti-wind board 1 81 Valve 1
40 Side cover 1 82 Seal mat 1
41 Bearing 9*12*11.5 1 83 Gasket 2
42 Clip 2
ENgINE
PArTS LIST
Please refer to the Schematic Drawing on page 40.
