gb
37
No. Description Qty. No. Description Qty.
1 Gear box complex 1 31 Drive shaft cover complex 1
2 Ring 26 1 32 Clutch cover 1
3 Ring 10 1 33 Ring 35 1
4 Bearing 6000-2RS/P5 2 34 Bearing 6202-2RS/P5 4
5 Small gear 1 35 Ring 15 1
6 Gasket 6 1 36 Driver 1
7 Screw M6*20 1 37 Rubber cover 1
8 Oil nozzle 1 38 Screw M5*15 3
9 Screw 5*12 1 39 Spring mat 5 2
10 Gasket 5 1 40 Gasket 5 2
11 Gear box cover 1 41 Plate 2
12 Upper safe cover 1 42 Plate (thread hole) 2
13 Bearing 6000/P5 1 43 Tie 1
14 Big gear 1 44 Grand gallous 1
15 Shaft 1 45 Screw M5*30 4
16 Bearing 6002-2RS/P5 1 46 Down plate 1
17 Ring 1 47 Middle plate 1
18 Upper cover 1 48 Screw M5 4
19 Down cover 1 49 Left grip 1
20 Down safe cover 1 50 Left handle 1
21 Screw M12 (left) 1 51 Right handle 4
22 Blade 1 52 Upper plate 1
23 Pole complex 1 53 Screw M5*25 1
24 Rubber cover 6 54 Right handle complex 1
25 Gasket 6 70 Nylon cutter 1
26 Drive shaft 1 79 Safe cover base 1
27 Aluminum pipe 1 80 Gasket 5 1
28 Cirlip 2 81 Screw 4
29 Screw M6*25 2 82 Safe cover 1
30 Screw M5 2 83 Down safe cover 1
Please refer to the Schematic Drawing on page 44.
Veuillez consulter le schéma à la page 40.
PArTS LIST
gENErAL
Please refer to the Schematic Drawing on page 39.
