hawa Folding Concepta 25 User Manual

HAWA-Folding Concepta 25
36
Tel. +41 44 767 91 91, Fax +41 44 767 91 78, www.hawa.ch
6.3
DE Bohrposition Korpusseite
FR Position de perçage côté corps de meuble
EN Drill position cabinet face
IT Schema di foratura fianco interno
ES Posición taladro lado módulo
EH Q3 Q4
1250 mm - 1850 mm (4’1 " - 6’ ") 370 mm (1’2 ") 555 mm (1’9 ")
1851 mm - 2600 mm (6’ " - 8’6 ") 620 mm (2’ ") 1155 mm (3’9 ")
Q5 T 66–=
Q6 T 77–=
7
32
-----
27
32
-----
9
16
-----
21
32
-----
7
8
--
3
8
--
13
32
-----
15
32
-----
