8
HEIGHT DIFFERENCE MODE
“∆HIGH”
Height difference mode measures the vertical
distance between two points. H1 will be
displayed rst, this is the rst point that is to be
measured from. Press the ON button and laze
this point. The height in relation to the range
nder will be displayed briey.
Then when H2 appears on the display aim at the second point that you are measuring to and press
the ON button. The height of the second aim point in relation to the range nder will be displayed
briey. Then ∆HIGH will be displayed. To the right of this you will see the difference in heights
between H1 and H2.
UNITS OF MEASUREMENT
The Hawke Laser Range Finder series can measure in meters or yards. To change between the two
hold the MODE button for 3 seconds.
When in angle mode the Laser Range Finder will measure in degrees.
Laser H1 Laser H2 Distance Measured
