9
Windows XP and 2000: Select Start >Settings > Control Panel >
Phone and Modem Options.
8 Enter your Location information and then click the Modems tab.
9 On the Modems page, select the installed USB modem, then click
the Properties button.
10 On the USB Modem Properties page, verify that the Maximum Port
Speed is set to 115,200.
11 Click the Diagnostics tab. On the Diagnostics page, click Query
Modem. You will see a list of AT commands and responses,
indicating that your modem is properly connected.
12 Click OK to close the Diagnostics page.
13 On the Phone and Modem Options dialog, click OK to exit.
That's it! Your modem installation is complete.
Note: The DATA light comes on when the modem is plugged into the
USB port of a powered-on computer and has been successfully
initialized by a properly-installed driver. It indicates that the modem
is ready to communicate data.
