USE ONLY HAYWARD GENUINE REPLACEMENT PARTS
16
pH Manual On Indicator (#8)
This green LED is illuminated when pH feeding is manually activated.
ORP Alarm Indicator (#10)
Illumination of this red indicator is accompanied by an audible alarm and indicates that ORP is
outside of the safe operating range. Check that the ORP chemical feeder is functioning properly
and that an adequate supply of sanitizer is available.
ORP Digital Display (#11)
The red digital numeric display of the ORP channel of the controller normally indicates the current
ORP (oxidation-reduction potential) of the pool or spa water passing through the filtration system.
Pressing the ORP Setpoint Adjustment Button until the red “SET” LED is illuminated causes the
ORP setpoint to be displayed.
ORP Setpoint Adjustment Mode Indicator (#12)
This green LED is illuminated whenever the controller is in the ORP setpoint adjustment mode.
ORP Automatic Control Indicator (#13)
This green LED is illuminated when ORP is under automated control.
ORP Manual Off Indicator (#14)
This red LED is illuminated when ORP feeding is manually disabled.
ORP Manual On Indicator (#15)
This green LED is illuminated when pH feeding is manually activated.
HCC 2000 Indicator Designations & Functions
ORP FEED MANUALLY DISABLED
DESIGNATION COLOR/TYPE DESCRIPTION
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
GREEN LED
RED LED
DIGITAL DISPLAY
pH SETPOINT ADJUSTMENT MODE INDICATORGREEN LED
GREEN LED
GREEN LED
RED LED
GREEN LED
GREEN LED
RED LED
DIGITAL DISPLAY
GREEN LED
GREEN LED
GREEN LED
RED LED
pH FEED INDICATOR
pH OUT OF RANGE ALARM
pH INDICATOR/SETPOINT/CALIBRATION
pH CALIBRATION MODE INDICATOR
AUTOMATIC pH CONTROL INDICATOR
pH FEED MANUALLY DISABLED
pH FEED MANUALLY ACTIVATED
ORP FEED INDICATOR
ORP OUT OF RANGE ALARM
ORP INDICATOR/SETPOINT
ORP SETPOINT ADJUSTMENT MODE INDICATOR
AUTOMATIC ORP CONTROL INDICATOR
ORP FEED MANUALLY ACTIVATED
