7
UHC Electrical & Gas Connection
Bonding Lug
Low Voltage
Gas Port
Alternate
Gas Port
Low Voltage
Wiring
High/Line
Voltage
L1
L
N
L2
G
G
240V
Factory Wired
120V
See Manual
The low voltage and high/line voltage compartments can be reversed but NOT shared.
