6.APPENDIX
(3) Spare Parts List
No.
Code
Name
Specifications
Qty
1
301090-00000004
Front box
ABS
1
2
20000-230596
Trademark
250X55
1
3
72200070
CP203
82300038 + 82400012
1
4
20000-220369
Fan net
ABS
1
5
20000-270004
Axial fan blade
Z500-145
1
6
20000-330132
DC
ZWS75-A
1
7
80701595
Back network
Galvanized sheet
1
8
301060-20180001
Finned heat exchanger
714x353x800x¢7x2 2.0
1
9
32009-210663
Support plate
Galvanized sheet 1.5 black 9005
1
10
80900216
Top cover
ABS black fine lines
1
11
32009-210662
Motor bracket assembly
Black 9005
1
12
32009-210658
Electrical cover
Galvanized sheet 1.0 black 9005
1
13
80600265
Titanium tube heat exchanger
¢12.7x7m+¢9.52x5m ¢160 thread
1
14
80701596
Right side panel
Galvanized sheet
1
15
32009-220029
Junction box
B ABS black
1
16
32009-210664
Middle partition
Galvanized sheet 1.0 black 9005
1
17
20000-110217
compressor
TNB220FLHMC
1
18
80701594
Chassis assembly
Galvanized sheet
1
19
2000-1460
Three links
¢6.5-2x¢6.5(T)x0.75 T2M
1
20
304030-00000002
Three links
40mm 1/2" T0305-10
1
21
20000-140150
Needle valve
¢9.52-2x¢6.35(T)x1.0
1
22
20000-140572
Electronic expansion valve
DPF(B)2.0C-008
1
23
20000-360157
Pressure Switch
0.30MPa/0.15MPa ±0.05 normally open
1
24
2001-3605
Pressure Switch
3.2MPa/4.4MPa ±0.15 normally closed
1
25
20000-360059
Pressure Switch
3.2MPa/4.0MPa ±0.15 normally closed
1
26
2004-1444
Filter (R410A)
¢9.7-¢9.7(¢28) T2Y2
1
27
20000-140618
Filter (R410A)
¢9.7-¢6.5(¢28) T2Y2
1
28
20000-360005
Flow switch
PSL-1 3/4
1
29
20000-140485
Four-way valve
DSF-11E-R410A
1
30
2000-3242
Sensor
150-502-98674(5K) 800mm
5
31
20000-390231
5-position terminal block
UTD-32/5P(L1、L2、PE、1、2)
1
32
20000-390049
Terminals
MSB 2.5-F
1
33
20000-390048
Terminals
MSDB 2.5-M
1
34
20000-390046
Terminals
MSB 2.5-M
1
35
20000-390047
Terminal block
D-MSB 1.5-F
1
36
20000-360297
Relay
HATF903AS30AC220 AC220V 30A
1
37
20000-360006
Contactor
HCC-1NU04AA
1
38
2000-3909
2-position terminal block
RS9211(450V~ 4mm2)
1
39
95005-310569
PC1002 Controller
20000-430177+35005-310569
1
40
20000-310170
Variable frequency drive
SA.FNB75GW.1
1
41
32009-210651
Electrical box assembly
Black 9005
1
