Hayward SUM5TA - Heat Pump Specifications

Description
Model number HP50TA* HP20654T HP20854T HP21104T HP21404T*
Refrigerant Type R-410A R-410A R-410A R-410A R-410A
Factory Charge 3 lbs. 0 oz. 3 lbs. 14 oz. 4 lbs. 2 oz 5 lbs. 6 oz. 5 LBS. 13.5 OZ.
Factory Test Pressure 440 psig 441 psig 441 psig 441 psig 441 psig
Compressor Amps 10.5 17.9 28 27 27
Compressor LRA 60 112 135 145 145
Fan Amps 1.3 1.8 1.8 1.8 2.4
Fan LRA 2.8 2.8 2.8 2.8 4.3
Minimum Water Flow 30 30 30 30 30
Maximum Water Flow 75 75 75 75 75
Maximum Water Inlet Temp. 108 108 108 108 108
Nominal Power Required (Watts) 2400 2830 3700 5400 6600
A/C Power 230v 60Hz 1Ph 230v 60Hz 1Ph 230v 60Hz 1Ph 230v 60Hz 1Ph 230v 60Hz 1Ph
Max. Circuit Breaker 20 40 60 60 60
Min. Circuit Ampacity 14.4 24 36 35 36.2
HeatPro Specifications
Description
Model number
SUM25TA
HML50TA
HCB50BTA
SUM3TA HML65TA
HCB65BTA
SUM4TA HML80TA
HCB80BTA
HET80BTA
SUM5TA
HML110TA
HCB110BTA
HET110BTA
HML125TA
HCB125BTA
HET125BTA
SUM8TA
Refrigerant Type R-410A R-410A R-410A R-410A R-410A R-410A
Factory Charge 3 LBS. 0 OZ. 3LBS. 11 OZ. 3 LBS. 12 OZ. 5 LBS. 5 OZ. 5 LBS. 12 OZ. 5 LBS. 13.5 OZ.
Factory Test Pressure 440 PSIG 440 PSIG 440 PSIG 440 PSIG 440 PSIG 440 PSIG
Compressor Amps 10.5 21 26.3 27 27 27
Compressor LRA 60 115 150 145 145 145
Fan Amps 1.3 1.3 1.3 2.4 2.4 2.4
Fan LRA 2.8 2.8 2.8 4.3 4.3 4.3
Minimum Water Flow 30 30 30 30 30 30
Maximum Water Flow 75 75 75 75 75 75
Maximum Water Inlet Temp. 108 108 108 108 108 108
Nominal Power Required (Watts) 2400 3130 3930 5600 6600 6600
A/C Power 230V 60Hz 1Ph 230V 60Hz 1Ph 230V 60Hz 1Ph 230V 60Hz 1Ph 230V 60Hz 1Ph 230V 60Hz 1Ph
Max. Circuit Breaker 20 40 60 60 60 60
Min. Circuit Ampacity 14.4 27.6 34.2 36.2 36.2 36.2
Summit/EasyTemp/HeatMaster/EnergyTherm Specifications
Heat Pump Specifications
