iren
SIREN OPERATION
BUTTON FUNCTION
Activates the siren. Subsequent presses will scroll through the siren tones.
Sounds the momentary siren until the button is released.
Switches off the siren tones.
VEHICLE
HORN
When the HORN wire is connected as shown in the wiring diagram, the vehicle
horn can be used to scroll through the siren tones. Holding the HORN on for over
0.2 of a second will activate the HRT tone.
Press the PTT button to activate the public address function.
PA Volume is displayed any time the PTT button is depressed, as shown below:
Level 1 Level 2 Level 3 Level 4
(Min) (Max)
+ Increase PA volume.
+ Decrease PA volume.
PUSH TO TALK
(PTT)
SIREN ON/SCROLL
MOMENTARY
SIREN OFF
MICROPHONE
