Technical Data
Unique system addresses over 1.000.000 combinations
Supply voltage 3,6 V
EMS category The mains supply is cut off by a STOP switch. Therefore,
the criteria for an elimination of errors according to EN ISO
13849-2 chapter D.5.3., table D.8 (non-opening of
contacts) are met. The performance level of the respective
receiver applies.
Frequency ranges 308 – 338 MHz, 405 – 475 MHz
1
, 865 – 870 MHz,
902 – 928 MHz; 1210 – 1258 MHz
1
DECT: 1880 – 1900 MHz
1
Not all frequency ranges available.
Channel spacing 12,5 / 20 / 25 / 50 / 250 kHz
DECT: 1,728 MHz
Transmitter antenna internal
Battery type BA223030 (NiMH)
Battery capacity 2100 mAh
Continuous operating time ca. 17 h (standard version without feedback)
Operating temperature range −20 °C – 70 °C
hazardous areas zone 2: −20 °C – 60 °C (−4 °F – 140°F)
Housing material impact-resistant plastic
Dimensions 240 x 68 x 58 mm (9.5 x 2.7 x 2.3 ")
Weight (incl. battery) ca. 550 g (1.2 lb.)
Protection class IP 65
