HBK T12HP - Page 76

T12HP
SPECIFICATIONS
76
T12HPType
500200100NVmNominal (rated) torque M
nom
1kNVm
Nominal (rated) torque M
nom
Power
Measurement frequency range Hz 80 (-1 dB)
Resolution W 1
Full scale value W
P
max
 M
nom
 n
nom

p
30
[M
nom
] in N⋅m
[n
nom
] in rpm
Temperature effect per 10 K in the nomi
nal (rated) temperature range on the
power signal, related to the full scale
value
% ±0.05n/n
nom
Linearity deviation including hysteresis,
related to the full scale value
% ±0.02n/n
nom
Sensitivity tolerance (deviation of the ac
tual measurement signal span of the
power signal related to the full scale
value)
% ±0.05
Temperature signal of the rotor
Accuracy K 1
Measurement frequency range Hz 5 (-1 dB)
Resolution K 0.1
Physical unit -
°C
Sample rate meas.
values/s
40
1)
See page 100.
2)
RS-422 complementary signals, note termination resistor.
3)
Output signal range in which there is a repeatable correlation between torque and output signal.
4)
See page 100.
5)
RS-422 complementary signals, note termination resistors.
Fieldbuses
CAN bus
Protocol - CAN 2.0B, CAL/CANopen-compatible
Sample rate
meas.
values/s
max. 4800 (PDO)
