HBK T12HP - Specifications; Nominal (Rated) Torque 100 N⋅M to 1 Kn⋅M

71
T12HP
SPECIFICATIONS
17 SPECIFICATIONS
17.1 Nominal (rated) torque 100NVm to 1kNVm
Type T12HP
Accuracy class 0.02
Torque measuring system
Nominal (rated) torque M
nom
NVm 100 200 500
kNVm 1
Nominal (rated) rotational speed n
nom
Option 4, code L
1)
rpm 15,000 12,000
Option 4, code H
1)
rpm 18,000 16,000
Option 4, code F
1) 8) 19)
rpm 22,000 20,000
Linearity deviation including hysteresis, related to nominal sensitivity
Fieldbuses, frequency output
10kHz/60kHz
Standard accuracy option:
for a max. torque in the range:
between 0% of M
nom
and 20% of M
nom
> 20% of M
nom
and 60% of M
nom
> 60% of M
nom
and 100% of M
nom
%
%
%
<±0.005
<±0.010
<±0.015
Higher accuracy option:
for a max. torque in the range:
between 0% of M
nom
and 20% of M
nom
> 20% of M
nom
and 60% of M
nom
> 60% of M
nom
and 100% of M
nom
%
%
%
≤± 0.003
≤± 0.005
≤± 0.007
Rel. standard deviation of repeatability
per DIN 1319, related to the variation of the output signal
Fieldbuses/frequency output % ≤± 0.005
Voltage output % ± 0.03
Temperature effect per 10 K in the nominal (rated) temperature range
on the output signal, related to the actual
value of the signal span
Fieldbuses/frequency output % <±0.02
Voltage output % <±0.05
