18.5” LCD Color Monitor HCL HCMELWBT11
15
5.2 Electrical Block Diagram
5.2.1 Main Board
Crystal 14.318MHZ
(X401)
FLASH ROM
SST25LF020A
(U402)
Scalar TSUM1PFR
(Include ADC, OSD, MCU)
(U401)
D-Sub Connector
(
CN101
)
Panel Interface
(CN403)
Key Control
Interface
(
CN401
)
