2. Installation
1. After separating the Speed Sensor coupler, plug in both the male and female
3-pole SH harness connectors. Make sure the connectors are fully seated.
2. Connect the 4-pole SH harness connector to the SH box.
3. Check whether the SH is installed and working properly:
- Have the ignition OFF.
- Press SEL and keep it depressed while you turn ignition ON.
[t] (test) is now indicated. Release the button.
The speedo should indicate a number other than zero.
- Rotate the rear wheel.
[t] should be blinking as the wheel turns.
- Press SEL to exit from Test mode.
The speedometer should work the same way as with no SH installed.
If the tests fail, disconnect the 3-pole and 4-pole connectors and check
whether the connector pins are bent or pushed out of position.
4. Find a place in your bike for the SH box regarding the followings:
- To be able to change the settings easily, place the unit where it is
quickly accessible.
- Frequently wet areas should be avoided.
- Do not place the unit very close to hot places like the engine or
exhaust pipe.
- Keep at least 2 cm (1”) distance from other electronics, such as the
bike's ECU or a Power Commander.
In most cases, the under-seat compartment is the best location for the box.
Secure the unit with the supplied Velcro strips.
5. Neatly route the SH harness from the 3-pole plugs to the mounting location,
preferably along the frame. To reduce possible interference, try not to route the SH
harness along with other electrical cables.
Do not bend
the SH harness near the SH connector. Otherwise the pins may break
over time.
To minimize cable stress, use the supplied cable ties to fasten the unit and the
harness to a solid part of the bike. Make sure that the SH switches won’t be hit by
loose objects in the trunk.
6. If you wish to use the Top Speed Recall feature, connect the 2-pole plug of the
remote button. Route the harness towards the front end of the bike and secure the
remote button at the dashboard with the supplied cable ties.
If you wish, you can easily change the harness length or replace the remote button
per your liking (any SPST momentary “push-to-make” switch can be used).
7. Please visit www.speedohealer.com and use our on-line calculator
to generate
set-up instructions for your SH. Alternatively, refer to the User’s Guide for
instructions.
