Hearth & Home Technologies • IFT-RC400 & IFT-ACM Installation Instructions • 2326-982 Rev. Q • 4/21 8
FLAME
SENSE
IGNITER
TO JUNCTION
BOX 110-120
VAC
FAN 110-120 VAC
LED
CONTROL
RF MODULE
ADAPTER
I
S
6 PIN
RED
BLK
ORANGE
(PILOT)
GREEN
(MAIN)
GRN/WHT/BLK
RED/
BLK
RED/
BLK
(OPTIONAL)
(OPTIONAL)
IFT-RC400
REMOTE
CONTROL
RED
BLK
BRN
BRN
JUMPER WIRE
BRN
WIRE ASSEMBLY
MODULE
RESET
SWITCH
(OPTIONAL ON SOME
MODELS ONLY)
ACCESSORY CABLE
POWER VENT
(OPTIONAL)
I. Wiring Diagram (continued)
IntelliFire Touch System Wiring Diagram - with Power Vent
Figure 16. IFT-RC400 Wiring Diagram with Power Vent
