HearthStone Quality Home Heating Products Inc Stowe Model #8321
02044-1
VENTING INFORMATION
VENT CONNECTION
Starter collar is installed by HearthStone.
1. The Stowe Direct Vent is approved for
installation only with the vent
connecting components listed on this
page and Simpson Dura-Vent Direct
Vent GS, AmeriVent Direct, or Secure
Vent systems. Use the following
instructions along with the pipe
manufacturer’s instructions to complete
the installation.
2. To attach the Restrictor Plate; see
instructions included with it. It will
attach from inside the firebox, after
removal of the brick patterned baffle.
The two screws required are included in
the appliance. Be sure you can see the
screw head for future adjustments.
a. NOTE: For minimum venting
configurations, discard the
restriction plate- see section
“Approved Vertical
Termination Venting
Configurations”
3. Install the rest of the vent system
according to the manufacturer’s
instructions.
Figure 9: Gasket & Stove Adapter Installation
Figure 7: Starter collar and Restriction Plate
assembly
1. Restriction Plate 5950-922
2. Gasket 4” 3160-155
3. Inner starter 924H1
4. Gasket 6” 3160-157
5. Outer Starter 924H1
