HearthStone 8321 - Specifications; Stowe Dimensions

HearthStone Quality Home Heating Products Inc Stowe Model #8321
02044-1
7
SPECIFICATIONS:
LISTED: Gas-Fired Direct-Vent Fireplace Heater
Model: Stowe Direct-Vent Gas Fireplace Heater (8321)
Testing Agency: Intertek Testing Services NA, Inc. (ITS)
Tested to: ANSI Z21.88-2002, CSA 2.33-M02, CAN/CGA2.17-M91
Certified for Canada, CSA P.4.1
Approved for Mobile Home Installation (see page 6)
Figure 1: Stowe Dimensions
FUEL TYPE:
NG LP
INPUT RATING (Btu/hr) 0-2000 ft 26,000 26,000
INPUT RATING (Btu/hr) 2000-4500 ft 25,500 25,500
ORIFICE SIZE (DMS) 0-2000 ft 40 53
ORIFICE SIZE (DMS) 2000-4500 ft 41 54
MANIFOLD PRESSURE - LO SETTING (in. W.c./kpa) 1.2/0.3 3.3/0.8
MANIFOLD PRESSURE - HI SETTING (in. W.c./kpa) 3.5/0.87 10.0/2.48
INLET PRESSURE - LO (in.w.c./kpa) 5.0/1.24 11.0/2.88
INLET PRESSURE - HI (in.w.c./kpa) 7.0/1.74 13.0/3.22
MINIMUMINPUT RATING (btu/hr) 15,600 15,600
MAXIMUMOUTPUT (btu/hr) 0-2000 ft 18,100 18,100
