HearthStone Quality Home Heating Products Inc Tucson Model #8700
VENTING COMPONENTS &
CONFIGURATION
The Tucson cannot be vented jointly with
any other solid fuel or gas appliance. It must
be vented directly to the outside of the
building using a proper termination as listed
in the manual. The only type of venting pipe
approved for use with your Tucson Direct-
Vent stove is Simpson Dura-Vent’s GS,
AmeriVent Direct and Secure Vent Direct-
Vent Pipe. The venting configurations are
shown in Figures 12 - 18. After determining
the venting configuration for your stove,
select the vent system that will
accommodate your installation.
Caution: Make sure all stove and
termination cap clearances have been
observed per the Owner’s Manual.
Caution: Be sure there is no wiring or
plumbing in the chosen location.
Caution: Venting terminals shall not be
recessed into a wall or siding.
Note: If further direction is needed for
installation, please refer to the venting
instructions, which are provided with the
venting components.
ACCEPTABLE DIRECT-VENT
TERMINATION CAP LOCATIONS
The vent/air intake termination clearances
above the high side of an angled roof are as
follows:
Roof Pitch Feet Meters
Flat to 6/12 1 0.3
7/12 to 9/12 2 0.6
10/12 to 12/12 4 1.2
13/12 to 16/12 6 1.8
17/12 to 21/12 8 2.4
Listed below are Simpson Dura-Vent,
AmeriVent Direct, and Secure Vent
components acceptable for installation,
along with the minimum venting kit
available. The venting system must be
comprised of the appropriate venting
components as specified.
APPROVED VENTING SYSTEM
COMPONENTS
*Component Description
90
0
Elbow
45
0
Elbow
6" Straight
9" Straight (Simpson only)
12" Straight
24" Straight
36" Straight
48" Straight
11"-14 5/8" Adjustable Pipe Length
Horizontal Vent Cap
Vertical Vent Cap
Snorkel 14
Vinyl Siding Standoff 4 x 6 5/8"
Round Ceiling Support Wall
Thimble Covers
Wall thimble
CHIMNEY LINER SYSTEM
1. Direct-Vent Chimney Liner Termination
Kit
2. Chimney Liner Flex
3. Co-Linear Flex Connector
4. Co-Axial to Co-Linear Appliance
Connect
*MINIMUM VENT KIT
*HearthStone Stove Starter Collar
45º Elbow
90º Elbow
(2) 9” Straight
Round Ceiling Support
Wall Thimble Cover
Wall Thimble
Horizontal Vent Cap
*Supplied by HearthStone
