HearthStone TUCSON User Manual

HearthStone Quality Home Heating Products Inc Tucson Model #8700
9
SPECIFICATIONS:
LISTED: DIRECT-VENT GAS HEATER
Listed: Gas-Fired Direct-Vent Fireplace Heater
Model: Tucson Direct-Vent Gas Fireplace Heater
Testing Agency: Intertek Testing Services NA Inc. (ITS)
Tested to: ANSI Z21.88-1998, CSA 2.33-M98, CAN/CGA2.17
Certified for Canada
Approved for
Mobile Home Installation (see page 7)
Figure 1: Tucson Dimensions
NG LP
Input rating (Btu/hr) 0-1370 m 26,000 26,000
Maximum output (Btu/hr) 0-1370 m 19,000 19,700
Minimum input rating (Btu/hr) 14,500 14,500
Orifice size DMS 0-1370 m 40 53
Man. pressure- HI setting (in.w.c./kPa) 3.5/0.87 10.0/2.48
Man. pressure- LO setting (in.w.c./kPa) 1.2/0.30 3.3/0.80
Inlet pressure-Lo (in.w.c./kPa) 5.0/1.24 11.0/2.88
