Heartland WaveReader G6 User Manual

6
Installation
www.heartlandMicroPayments.com
7
Connect J1 of the
interface harness to
the mating connector
of the WaveReader-
SPIN.
8
Attach the WaveReader-
SPIN to Tilt Bracket using
four of the (3/16”) SRW-
632X.1188PM screws that
were provided. A magnetic
tip is helpful for securing the
two screws that must be
accessed via the outer slots
on the bracket.
6
Pull the wiring harness
all the way through the
large hole in the Tilt
Bracket.
DOC-WR-SPIN-INST
