‘S’ Series
13 SEER
Single Zone Ductless Mini-Split Sytems
11
Cooling Only Heat Pump Models
FEATURES
SMA09SC-0 SMA12SC-0 SMA18SC-1 SMA24SC-1 SMH09SC-0 SMH12SC-0 SMH18SC-1 SMH24SC-1
Power Supply 115-1-60 115-1-60 208/230-1-60 208/230-1-60 115-1-60 115-1-60 208/230-1-60 208/230-1-60
Cooling Capacity (BTUH)
9,000 12,000
16,200/
18,000
21,600/
23,000
9,000 12,000
16,200/
18,000
21,600/
23,000
Cooling Amps
7.3 10.0 6.8/6.8 8.8/8.8 7.3 10.0 6.8/6.8 8.8/8.8
Dehumidify (Pts/Hr.)
2.1 2.5 3.8 5.3 2.1 2.5 3.8 5.3
Heating Capacity
(BTUH)
N/A N/A N/A N/A 10,000 12,500
16,200/
18,000
21,600/
23,000
Heating Amps
N/A N/A N/A N/A 7.6 10.0 7.0/7.0 8.8/8.8
HSPF
N/A N/A N/A N/A 7.8 7.8 7.8 7.8
INDOOR UNIT
Air flow (CFM)
342/271/218 471/412/371 618/589/547 795/688/624 341/271/218 500/430/394 618/589/547 795/688/624
Fan Speeds (C/H/F)
3/–/3 3/–/3 3/–/3 3/–/3 3/3/3 3/3/3 3/3/3 3/3/3
AIR DIRECTION
Vertical Modulating
Remote Remote Remote Remote Remote Remote Remote Remote
Horizontal (left/right)
Manual Manual Manual Manual Manual Manual Manual Manual
Random Swing
Standard Standard Standard Standard Standard Standard Standard Standard
INDICATOR LAMPS
ON/OFF
Standard Standard Standard Standard Standard Standard Standard Standard
24 Hr Timer/Sleep Mode
Standard Standard Standard Standard Standard Standard Standard Standard
Defrost
N/A N/A N/A N/A Standard Standard Standard Standard
Temperature Setting
Remote Temperature Set Range 62° F to 88° F Remote Temperature Set Range 62° F to 88° F
INDOOR UNIT DIMENSIONS
Width (inches)
31
1
/8 36
1
/4 42
1
/2 49
3
/16 31
1
/8 36
1
/4 42
1
/2 49
3
/16
Height (inches)
10
7
/16 11
1
/2 13 12
13
/16 10
7
/16 11
1
/2 13 12
13
/16
Depth (inches)
7
11
/16 8
7
/8 99
1
/16 7
11
/16 8
7
/8 99
1
/16
Net Wt/Shipping Wt (lbs)
16.5/19.8 28.7/33.0 33.0/46.3 39.7/55.1 16.5/19.8 28.7/33.0 33.0/46.3 39.7/55.1
OUTDOOR UNIT DIMENSIONS
Width (inches)
30
11
/16 29
15
/16 33
1
/4 35
1
/4 30
11
/16 29
15
/16 33
1
/4 35
1
/4
Height (inches)
21
5
/8 23
1
/4 27
3
/8 33
7
/8 21
5
/8 23
1
/4 27
3
/8 33
7
/8
Depth (inches)
9
7
/8 11
1
/4 13
3
/16 13 9
7
/8 11
1
/4 13
3
/16 13
Net Wt/Shipping Wt (lbs.)
70.5/77.1 79.3/86.0 116.9/125.7 141.1/150.0 68.3/74.9 83.8/90.4 116.9/125.7 143.3/152.1
ELECTRICAL DATA OUTDOOR UNIT*
Main Power Connection
Outdoor Unit Outdoor Unit Outdoor Unit Outdoor Unit Outdoor Unit Outdoor Unit Outdoor Unit Outdoor Unit
Max. Circuit Ampacity
13.6 17.2 12.7 16.5 13.6 17.2 12.7 16.5
Max. Fuse/HACR
Circuit Breaker
15A 20A 15A 20A 15A 20A 15A 20A
Recommended Indoor/
Outdoor Connecting
Cable Type (SJOW)
18AWG
4 conductor
300V or heavier
18AWG
4 conductor
300V or heavier
Line Voltage
per NEC*
Line Voltage
per NEC*
18AWG
4 conductor
300V or heavier
18AWG
4 conductor
300V or heavier
Line Voltage
per NEC*
Line Voltage
per NEC*
LINE SETS O.D. (inch) / REFRIGERANT
Refrigerant
R-410A R-410A R-410A R-410A R-410A R-410A R-410A R-410A
Liquid (flare) (inch)
1/4 1/4 1/4 3/8 1/4 1/4 1/4 3/8
Suction (flare) (inch)
3/8 1/2 1/2 5/8 3/8 1/2 1/2 5/8
Max. Line Set Length
1
65.5 feet 65.5 feet 82 feet 82 feet 65.5 feet 65.5 feet 82 feet 82 feet
Max.Outdoor Elevation
2
26 feet 26 feet 32.8 feet 32.8 feet 25.6 feet 25.6 feet 32.8 feet 32.8 feet
C US
Warranty—5 years on compressor, 1 year on parts
(Some limitations apply; see printed warranty for details.)
*Always follow local, state and national electrical codes. Main power connection is 208-230V.
1
Min. 15 ft. line set recommended.
2
Oil trap should be installed every 16.5 to 23 feet (5-7m).
Design, specifications and performance data subject to change without notice.
