15
‘V’ Series InverterFlex
Multi-Zone Ductless Mini-Split HeatPumps
Mix and match indoor units up to the maximum BTUHs for each
system. The chart on the right shows the various combinations.
Note that outdoor and indoor units are ordered separately; “A”
indicates outdoor unit, “B” indicates indoor unit.
For instance, to order a 33,000 BTUH tri-zone, you’ll specify one
A-VMH36QC, two B-VMH12FC, and one B-VMH09FC.
Outdoor Units
FEATURES
A-VMH18DC-1 A-VMH27TC-1 A-VMH36QC-1
Power Supply
208/230-1-60 208/230-1-60 208/230-1-60
System Cooling Capacity (BTUH)
18,000 27,000 36,000
SEER
16.0 16.0 15.0
Cooling Amps
7.5 11.0 15.0
System Heating Capacity (BTUH)
19,000 28,000 38,000
Heating Amps
7.6 11.2 15.0
HSPF
7.7 7.7 8.5
OUTDOOR UNIT DIMENSIONS
Width (inches)
33
1
/4 33
1
/4 39
Height (inches)
27
3
/8 27
3
/8 37
Depth (inches)
13
3
/16 13
3
/16 13
Net Wt/Shipping Wt (lbs.)
117.9/125.7 125.7/133.4 189.6/198.4
ELECTRICAL DATA OUTDOOR UNIT*
Main Power Connection
Outdoor Unit Outdoor Unit Outdoor Unit
Min. Circuit Ampacity
10.5 16.0 15.4
Max. Fuse/HACR Circuit Breaker
15 20 20
Recommended Indoor/Outdoor
Connecting Cable (SJOW)
Line Voltage
per NEC*
Line Voltage
per NEC*
Line Voltage
per NEC*
LINE SETS O.D. (inch) / REFRIGERANT
Refrigerant
R-410A R-410A R-410A
Liquid (flare) (inch)
1/4 1/4 1/4
Suction (flare) (inch)
3/8 3/8 3/8
Maximum Line Set Length
1
49.2 feet 49.2 feet 49.2 feet
Maximum Elevation (outdoor)
2
32.8 feet 32.8 feet 32.8 feet
InverterFlex Outdoor/Indoor Combinations
OUTDOOR UNIT ZONES INDOOR UNITS TOTAL BTUH
A-VMH18DC-1
Dual 9K + 9K
18,000
A-VMH27TC-1
Dual 9K + 12K
21,000
Dual 12K + 12K
24,000
Tri 9K + 9K + 9K
27,000
A-VMH36QC-1
Tri 9K + 9K + 12K
30,000
Tri 9K + 12K + 12K
33,000
Tri 12K + 12K + 12K
36,000
Quad 9K + 9K + 9K +9K
36,000
Indoor Units
FEATURES B-VMH09FC-1 B-VMH12FC-1
INDOOR UNIT
Cooling Capacity BTUH
9,000 12,000
Heating Capacity BTUH
10,000 13,000
Air flow (CFM)
335/283/206 412/306/247
Dehumidification (Pts/Hr)
2.3 2.5
Fan Speeds
33
AIR DIRECTION
Vertical Adjustment
Manual Manual
Horizontal Modulating
Yes Yes
Random Swing
Yes Yes
INDICATOR LAMPS
ON/OFF
Yes Yes
24 Hr. Timer/Sleep Mode
Yes Yes
Defrost
Yes Yes
Temperature Setting
On Remote: 62° F – 88° F
INDOOR UNIT DIMENSIONS
Width (inches)
31
5
/16 33
1
/4
Height (inches)
10
5
/8 11
1
/4
Depth (inches)
6
1
/4 6
1
/4
Net Wt/Shipping Wt (lbs)
22/26.5 22/26.5
Liquid (flare) (inch)
1/4 1/4
Suction (flare) (inch)
3/8 1/2*
C US
*Always follow local, state and national electrical codes. Main power connection is 208-230V.
1
Min. 15 ft. line set recommended
2
Oil trap should be installed every 16.5 to 23 feet (5-7m).
Design, specifications and performance data subject to change without notice.
Ambient Operating Temperature: 5°
- 122° F (cooling); 5° - 93.2° F (heating)
*Adapter included with indoor section
* 9K = Model No. B-VMH09FC-1, 12K = Model No. B-VMH12FC-1
Warranty—6 years on compressor, 2 years on parts
(Some limitations apply; see printed warranty for details.)
