13
‘V’ Series
Single Zone Ductless Mini-Split Systems with Inverter Technology
C US
Heat Pump Models
FEATURES VMH09SC-1
**
VMH12SC-1
**
VMH18SC-1
**
VMH24SC-1
Power Supply
208/230-1-60 208/230-1-60 208/230-1-60 208/230-1-60
Cooling Capacity (BTUH)
9,000 12,000 17,500 23,000
SEER
19 20 17 17
Cooling Amps
3.5 4.7 6.7 9.7
Dehumidification (Pts/Hr.)
2.3 2.5 3.6 4.7
Heating Capacity (BTUH)
10,000 12,500 18,000 24,000
Heating Amps
3.8 5.4 6.3 9.5
HSPF
9.0 9.5 8.5 9.0
INDOOR UNIT
Air flow (CFM)
400/318/288 430/341/312 624/589/506 736/677/589
Fan Speeds (Hi/Med/Lo)
3333
AIR DIRECTION
Vertical Modulating
Remote Remote Remote Remote
Horizontal (left/right)
Manual Manual Manual Manual
Random Swing
Standard Standard Standard Standard
INDICATOR LAMPS
ON/OFF
Yes Yes Yes Yes
24 Hr. Timer/Sleep Mode
Yes Yes Yes Yes
Defrost or Hot Start
Yes Yes Yes Yes
Temperature Setting
On Remote: 62° F – 86° F temperature setting range
INDOOR UNIT DIMENSIONS
Width (inches)
33
1
/4 33
1
/4 42
1
/2 42
1
/2
Height (inches)
11
1
/4 11
1
/4 12
5
/8 12
5
/8
Depth (inches)
6
1
/2 6
1
/2 7
7
/8 7
7
/8
Net Wt/Shipping Wt (lbs)
19.8/24.3 19.8/24.3 31.9/44.0 31.9/44.0
OUTDOOR UNIT DIMENSIONS
Width (inches)
29
15
/16 29
15
/16 33
1
/4 35
1
/4
Height (inches)
23
1
/4 23
1
/4 27
3
/8 33
7
/8
Depth (inches)
11
1
/4 11
1
/4 13
3
/16 13
Net Wt/Shipping Wt (lbs.)
83.8/90.4 86.0/92.6 110.2/119.0 136.7/147.7
ELECTRICAL DATA OUTDOOR UNIT*
Main Power Connection
Outdoor Unit Outdoor Unit Outdoor Unit Outdoor Unit
Max. Circuit Ampacity
9 9.5 15 13.5
Max. Fuse/HACR Circuit Breaker
15 15 15 15
Recommended Indoor/Outdoor
Connecting Cabler Type (SJOW)
Line Voltage
per NEC*
Line Voltage
per NEC*
Line Voltage
per NEC*
Line Voltage
per NEC*
LINE SETS O.D. (inch) / REFRIGERANT
Refrigerant
R-410A R-410A R-410A R-410A
Liquid Connection (flare) (inch)
1/4 1/4 1/4 3/8
Suction Connection (flare) (inch)
3/8 1/2 1/2 5/8
Maximum Line Set Length
1
65 feet 65 feet 82 feet 82 feet
Maximum Elevation (outdoor)
2
26 feet 26 feet 32.8 feet 32.8 feet
Warranty—6 years on compressor, 2 years on parts
(Some limitations apply; see printed warranty for details.)
*Always follow local, state and national electrical codes. Main power connection is 208-230V.
**Energy Star compliant models.
1
Min. 15 ft. line set recommended.
2
Oil trap should be installed every 16.5 to 23 feet (5-7m).
Design, specifications and performance data subject to change without notice.
