Heath Zenith Motion Sensing 3-Way Wall Switch SL-6107 User Manual

-3-
595-4514-14
INSTALLATION
AUTO
OFF ON
AUTO
OFF ON
SL-6107 SWITCH 1
ST
IN CIRCUIT
WHITE
FROM
POWER
SOURCE
BLACK BLACK
WHITE
RED
(In Wall)
BROWN
BLACK
EXISTING
3-WAY SWITCH
ADD JUMPER WIRE
SL-6107
RED
(From 6107)
WHITE
BLACK
*COMMON
ONE SL-6107 SWITCH IN CIRCUIT
WHITE
FROM
POWER
SOURCE
BLACK
WHITE
BLACK
WHITE
BLACK
*COMMON *COMMON
SL-6107 SWITCH 2
ND
IN CIRCUIT
WHITE
FROM
POWER
SOURCE
BLACK
BLACK
WHITE
RED
(In Wall)
BROWN
BLACK
EXISTING
3-WAY SWITCH
ADD JUMPER WIRE
SL-6107
RED
(From 6107)
WHITE
BLACK
*COMMON
RED
(In Wall)
*COMMON-Used for illustrative Purposes Only. Check Your Switch. The common may be in a different loca-
tion, depending on the brand of your switch.
RED is used to represent the second wire between two standard three-way switches. This may not be the color
used in all installation. If you are not sure about your wiring, call an electrician for installation help. There is also
a RED wire on the SL-6107 switch. Check the instructions above closely and do not confuse the two.
See pages 4 through 6 for detailed instructions for installing and
wiring the SL-6107 Wall Switch.

Heath Zenith Motion Sensing 3-Way Wall Switch SL-6107 Specifications

General

Brand	Heath Zenith
Model	Motion Sensing 3-Way Wall Switch SL-6107
Category	Switch
Language	English
