component nu umber (R2, C4, “etc .). Use these
numbers when you want to identifv the same
SUES fie eit aitity the oa@lile
part in the various sections of the Manual.
These numbers, which are especially useful if a
part has to be replaced, appear:
— In the Parts List,
— At the beginning of each step where a
component is installed,
— In some illustrations,
— Inthe Schematic,
— In the section at the rear of the Manual.
When you are instructed to cut something to a
particular length, use the scales (rulers) pro-
vided at the bottom of the Manual pages.
SAFETY WARNING: Avoid eye injury when
aL lan de op tha: 11
oft excess lead lengths. Hola ULC 1CaUS 35U UIC
fly toward your eyes.
Soldering is one of the most important operations you
will perform while assembling your kit. A good sol-
der connection will form an electrical connection be-
tween two parts, such as a component lead and a
circuit board foil. A bad solder connection could pre-
vent an otherwise well-assembled kit from operating
properly.
It is easy to make a good solder connection if you
follow a few simple rules:
—
No
Use the right type of soldering iron. A 25 to
40- watt pencil soldering iron with a 1/8”
Loct
3/16" chisel Or pyramid tip works DESL.
NOTE: Always use rosin core, radio-type solder
(60:40 or 50:50 tin-lead content) for all of the solder-
ing in this kit. This is the type we have supplied with
the parts. The Warranty will be void and we will not
ax, te ~s :] o anldee ar nacte haa
service any kit in which acid core solder or pasie nas
been used.
