feo
FIL
ATEEIT®
Position
the
circuit
board
as
shown.
Then
complete
each
step
on
the
Pictorial.
NOTE:
When
you
install
a
diode,
always
match
the
band
on
the
diode
with
the
band
mark
on
the
circuit
board.
A
DIODE
WILL
NOT
WORK
IF
(IT
IS
INSTALLED
BACKWARDS.
See
Detail
1-1A.
te
Install
eight
1N2071
diodes
(#57-27)
at
D9,
07,
010,
D8,
and
D5, D3,
D6,
D4.
(IMPORTANT:
THE
BANDED
END
OF
DIODES
CAN
BE
MARKED
IN
A
NUMBER
OF
WAYS.
BANDED
END
Detail
1-1A
/
y
Me
Ce
DO
ae
U\)
201:
BZT110A
zener
diode
(#56-48).
-€0)
02:
1N4149
diode
(#56-56).
(+)
Solder
the
leads
to
the
foil
and
cut
off
.
the
excess
lead
lengths.
&
)
R26:
51
Q
(green-brown-black).
Use
the
1/2-watt
resistor,
4)
R29:
1.5
82
(brown-green-gold).
R25:
10
Q,
1/4-watt
(brown-black-
black).
A)
R28:
470
2
(yellow-violet-brown).
OT
|
|
=
DO
R12:
470
Q
(yetlow-violet-brown).
R11:
470
2
(yellow-violet-brown).
R6:
1000
Q,
1/4-watt
(brown-black-red).
R5:
1000
Q,
1/4-watt
(brown-black-red).
R7:
1000
2,
1/4-watt
(brown-black-red).
R23:
820
22
(gray-red-brown).
R24:
220
2
(red-red-brown).
Solder
the
leads
to
the
foil
and
cut
off
the
excess
lead
lengths.
R27:
680
Q
(blue-gray-brown).
NOTE:
To
prepare
wires
as
in
the
following
steps,
cut
them
to
the
indicated
lengths
and
remove
1/4”
of
insulation
from
each
end.
When
bare
wire
is
called
for,
cut
a
blue
wire
to
the
indicated
length
and
remove
all
of
the
insulation,
————$—$—$<$<$
ET
——$——_—
T
(.-})
Prepare
the
following
wires:
3”
blue
1”
bare
(
)
3°
blue
wire.
B)
,
1”
bare
wire,
Solder
the
leads
to
the
foil
and
cut
off
R8:
1000
$2,
1/4-watt
(brown-black-red).
R3:
1000
2,
1/4-watt
(brown-black-red).
R4:
1000
2,
1/4-watt
(brown-black-red).
R9:
1000
Q,
1/4-watt
(brown-black-red).
R2:
470
Q
(yellow-violet-brown).
R1:
100
kQ
(brown-black-yellow).
PICTORIAL
1-1
FOR
GOOD
SOLDER
CONNECTIONS,
YOU
MUST
KEEP
THE
SOLDERING
IRON
TIP
CLEAN.
“ze
WIPE
IT
OFTEN
=¢4-
OE
WITH
A
DAMP
Kiccas
SPONGE
OR
CLOTH.
-
the
excess
lead
lengths.
(+)
Solder
the
leads
to
the
foil
and
cut
off
the
excess
lead
lengths.
oO
Y%
%
41
(INCHES)
2 3
4
5
6
7
fve
se
sve,
ve],
pt
tT
tt
tt
Lii,tei
toa,
|
brett
ns
A
a
Sn
an
Pn
ae
a
SL
Sn
SL
A
Sn
Se
a
a
oOo
5
+
(CM)
2 3
4
5
6
r)
9
10
"1
12
13
14
415
16
17
