DESCRIPTION
KEY OTY.
No.
1 - Watt
A4 () 1 10 kQ, 10% (brown-
black-orange)
CAPACITORS
A5 T) 2 10pF ceramic
AS {<) 1 47 pF ceramic
AS (--) 5 .01 uF ceramic
A6 (*) 1 15 uF tantalum
A7 (- ) 2 40 uF electrolytic
A7 (-) 2 1000 uF electrolytic
PART
No.
1-9-1
21-3
21-32
21-16
25-252
25-20
25-111
CIRCUIT
Component No.
R13
c1,C9
C2
C3, C4,
C5, C6,
C7?
C8
C101, C102
C103, C104
DIODES-TRANSISTORS-INTEGRATED CIRCUITS
B1 (-) 1 BZT110A zener
diode
5
B1 (*) 1 1N4149 diode
B1 (*) 1 MZ500-10 zener
diode
B1 \ ) 1 $25.0 zener diode
B1 (4) 8 1N2071 diode
56-48
56-56
56-63
56-85
57-27
ZD1
D2
ZD102
2D101
D3, D4,
D5, D6,
D7, DB,
D9, D10
NOTE: Transistors and integrated circuits are marked for identification in
one of the following four ways:
1. Part number.
2. Type number. (For integrated circuits this refers only to the
numbers, the letters may vary.)
3. Part number and type number.
4, Part number with a type number other than the one listed.
B2 (*) 1 2N3393 transistor 417-118 Q1
B2 (*.) 2 2N5771 transistor 417-292 Q4, 05
B2 () 2 MPSLO1 transistor 417-811 Q2, 03
B3 ("4 1 2N5294 transistor 417-175 0101
B4 (°) 1 SN7474N integrated 443-6 IC1
L. circuit
B4 (*‘) 6 SN7490N integrated 443-7 IC2, IC3,
circuit C4, IC5,
IC6, 1C7
o—lbD—
C
7
am |
P Nore: HEATH PART NUMBERS
ARE STAMPED ON MOST DIODES.
———=1
OR
OR
