KEY QTY. DESCRIPTION PART CIRCUIT
No. No. Component No.
HARDWARE
NOTE: The hardware may be in more than one packet. Open all hardware
packets in this pack before you check the hardware against the Parts List.
The hardware is shown actual size.
#6 Hardware
i TTT
Di {*) 4 #6 x 1/4” sheet 250-170 aD ¢
: metal screw
D2(> 12 6-32 3/8" screw 250-89 _
D3¢} 12 632nut 252-3
D4 (%) 13 #6 lockwasher 254-1 —
D5 (>) 5 #6 solder lug 259-1
Other Hardware
a
D6 (*) 4 4-40 nut 252-15
D7 (<) 2 Control nut 252-7
D8 (>) 2 Control flat 253-10
washer
D9 (¢*) 1 — Push-on nut 252-9 (0)
WIRE-SLEEVING
rs
(C)
ee
(-)) 8” Red 344-52
(™) 48” Blue 344-56
(~ 8" White-red 344-72
( 7 9” White-yellow 344-74
(~) 26" Black stranded 344-2
(7) 36” Large shielded 343-2
cable
(ss) 12” Small shielded 343-15
; cable
( -» 1-1/2” Large clear 346-60
- sleeving
(4 5” — Small clear 346-2
sleeving
(2, 2-1/2" Heat-shrinkable 346-46
, sleeving
(4) 6 Line cord 89-23
