2 Heatilator • SIM-3630, SIM-3933, SIM-4236, SIM-4842 Decorative Front Instructions • 2382-930 Rev. B • 9/17
INSTALL HOOD (All Models)
1. Locate the four screws inside the upper section of the
appliance.
2. Loosen and partially unscrew all four screws about 1/8
inch using a 1/4 inch drill driver.
3. Slide the hood into position under the screw heads.
See Figure 3.
4. Using a 1/4 inch drill driver, tighten the four screws. Do
not overtighten.
Figure 3. Install Hood
2. Install a shoulder screw in the outermost hole from
where the latches were removed. See Figure 2.
Shoulder screws are located in the manual bag. Tight-
en shoulder screw until snug. Do not overtighten.
Figure 2. Install Shoulder Screw (1 Per Side)
OUTERMOST LATCH HOLE
