Heatmaster TC series User Manual

EN • 9
ENGLISHFRANCAISNEDERLANDSESPAÑOLITALIANODEUTSCH
664Y2800.B
TECHNICAL CHARACTERISTICS
Natural gas categories
BE FR NL LU DE
AT - CH - CZ - DK - ES - IT
FI - UK - IE - PT - SE - GR
HU
I 2E(S)B
[G20] 20 mbar – [G25] 25 mbar
I 2E(R)B *
[G20] 20 mbar – [G25] 25 mbar
I 2Er
[G20] 20 mbar – [G25] 25 mbar
I 2L
[G25] 25 mbar
I 2E
[G20] 20 mbar
I 2ELL
[G20] 20 mbar – [G25] 20 mbar
I 2H
[G20] 20 mbar
I 2HS
[G20] 25 mbar
(*) HeatMaster
®
85 TC
Propane categories
DK - NL
NO - IT
BE - CH - ES
FR - UK - IE
PT - FI - SE
IT - GR
AT - CH
CZ - ES
NL - DE
LU - HU
BE - CH
ES - FR
UK - IE
IT - PT
CZ - DK - ES
FI - FR - UK
IE - IT - NL
NO - PT - SE
AT - CH
CZ - DE
FR
I 3P
[G31] 30 mbar
I 3P
[G31] 37 mbar
I 3P
[G31] 50 mbar
I 3+
[G30 + G31] 28 / 30 / 37 mbar
I 3B
[G30] 28 / 30 mbar
I 3B
[G30] 50 mbar
DOMESTIC HOT WATER FEATURES
HeatMaster
®
35 TC
HeatMaster
®
85 TC
Operating conditions at 80°C
Peak fl ow at 40°C [ΔT = 30°C]
L/10’
419 850
Peak fl ow at 40°C [ΔT = 30°C]
L/60’
1312 3177
Constant fl ow at 40°C [ΔT = 30°C]
L/h
1057 2793
Peak fl ow at 45°C [ΔT = 35°C]
L/10’
381 722
Peak fl ow at 45°C [ΔT = 35°C]
L/60’
1080 2717
Constant fl ow at 45°C [ΔT = 35°C]
L/h
898 2394
Peak fl ow at 60°C [ΔT = 50°C]
L/10’
224 459
Peak fl ow at 60°C [ΔT = 50°C]
L/60’
692 1778
Constant fl ow at 60°C [ΔT = 50°C]
L/h
578 1583
Pre-heat time
minutes
37 35
