Heatmaxx SRPH98 - Step 3: Middle Plate Attachment; Step 4: Upper Supports Attachment

12
9
CC
CC
$66(0%/<,16758&7,216
9
11
12
12
13
13
HH
6WHS
Unscrew the pre-assembled M4 x 25 screws (HH) on the glass tube base (#11), then remove the glass tube
base (#11) from the middle plate (#12), and put the M4 x 25 screws (HH) and the glass tube base (#11) aside
for Step 7.
Attach the middle plate (#12) to the lower supports (#13) with (8) M5 x 12 screws (CC) as illustrated.
6WHS
Attach (4) upper supports (#9) to the lower supports (#13) with (16) M5 x 12 screws (CC) as illustrated.
+DUGZDUH8VHG
M5 x 12 Screw
8 pcs
CC
+DUGZDUH8VHG
M5 x 12 Screw
16 pcs
CC
