4
Fix thermostat to the wall
Align the holes in the back of the thermostat with the holes in your pre
installed electrical back box and x in place with the screws provided.
Now reconnect the ribbon connection and re-seat the face plate (bottom
edge rst). Ensure the thermostat is securely xed before continuing. You
should hear a loud click when the face plate is secure.
1
2
2
3 4 5
1. Faceplate
2. Provided screws
3. Ribbon connectors
4. Back plate
5. Back box
