Installation
Push the three clips located on the bottom of the thermostat in with a
screwdriver, releasing the face plate.
Once the face plate has been gently released, disconnect the ribbon
cable to free the face plate from the main body of the thermostat. Put the
faceplate somewhere it will not get damaged.
Wiring diagram
Loosen the tension screws to allow the wires to be inserted and xed.
Position the cables as shown in the wiring diagram and ensure each
screw is tightened correctly. Ensure system is correctly earthed.
Sensor
7 6 4 3 2 15
LL
3600W/16A
230V/AC
NN
