Hebo TRS ONE 2021 - 15 - Handlebar and Instrument Panel with Electric Start; Left-hand Handlebar Controls (Electric Start); Central Instrument Panel (Electric Start); Right-hand Handlebar Controls (Electric Start)

25
On the left side of the handlebar are:
a) - Clutch lever.
b) - Horn.
c) - Engine stop button.
d) - Main/dip beam switch, and indicator switch -
(Motorcycle approval)
The instrument panel is in the centre of the hand-
lebar (e). (More information and instructions for use
are given in later sections of this manual).
On the right-hand side of the handlebar you
can nd:
g - Brake lever.
h - Throttle.
i- Electric start button
HANDLEBAR AND INSTRUMENT PANEL WITH ELECTRIC START
15 - Handlebar and Instrument panel with electric start
f) At the back of the headlight
is the CDI map switch. Here,
you can choose between the
positions:
I: Wet or 0: Dry.
Left-hand side of the handlebar. Central part of the handlebar. Right-hand side of the handlebar.
a
b
c
d
e
f
g
h
i
