On the left side of the handlebar are:

a) - Clutch lever.

b) - Horn.

c) - Engine stop button.

d) - Main/dip beam switch, and indicator switch - (Mo-

torcycle approval)

The instrument panel is in the centre of the handlebar

(e). (More information and instructions for use are gi-

ven in later sections of this manual).

On the right-hand side of the handlebar you can

nd:

g - Brake lever.

h - Throttle.

HANDLEBAR AND INSTRUMENT PANEL STANDARD

15 - Handlebar and Instrument panel

f) At the back of the headlight

is the CDI map switch. Here,

you can choose between the

positions:

I: Wet or 0: Dry.

Note: Only in competition mo

del

Left-hand side of the handlebar. Central part of the handlebar. Right-hand side of the handlebar.
