PACKAGE CONTENTS
1x machine body, connecting material, remote control, instructions for use.
• Standard accessories are subject to change without notice.
• This product requires assembly. The product must be assembled correctly before use.
ASSEMBLY
CAUTION! A
The exhaust hose must always be led out of the room; otherwise the air-conditioning
will not work properly or will not work at all.
The placing of the exhaust hose
can be done by making a hole in the wall, window, etc.
• Create a round hole with a diameter of about 155–160 mm and pass the hose through it.
On the outside, it is recommended to fit the hose with an air non-return valve. (Not included)
Note: I
To install the exhaust hose in the sliding window, you have the option to purchase
a window installation kit.
EXHAUST HOSE ASSEMBLY
C Only use the hose included in the package. Attach the hose to the rear of the air
conditioner.
• Attach the hose to the rear part of the air conditioning unit.
• Be careful not to bend the exhaust hose excessively as it will cause the appliance to overheat
and shut down when damp air blows up.
• (FIG. 5 and 6) show the wrong hose position
• The hose can be extended from 300 mm to 1500 mm, but for maximum efficiency, use
the shortest possible hose length.
CAUTION! A
The length of the exhaust hose is specifically designed to meet the product’s requirements.
Don‘t change it or extend it to another hose. Doing so may cause the unit to malfunction
CARBON FILTER INSTALLATION (FIG 10)
1. Remove the filter frame from the unit.
2. Remove the activated carbon filter from the plastic bag.
3. Insert the activated carbon filter into the back of the unit.
4. Place the filter frame back into the unit.
CONTROL
AIR VENTILATION SETTINGS
Open the horizontal grid before using the unit! Adjust the grid to the desired direction.
