LCD Information
Icon Definition Function Declaration
When this icon is on, high current charging mode is active
and provides fast boost charging of the batteries. Fast
charging mode: 1 battery / 1.5 A ; 2 batteries / 0.8 A
When it appears, 8.4 V charging mode for DV batteries
is in progress
When it appears, 16.8 V charging mode for Pro DV
batteries is in progress
When battery is on the charger and charging process
starts, the battery charging icon will be displayed.
Progress icon will be displayed one by one.
It shows that the battery is fully charged and ready.
It shows the battery capacity charging percent rate
Displays 5V USB power out
Displays that the 12 V DC IN is present (car cable in)
Shows presence of the battery on the charger/channel
Fast speed
charging mode
8.4 V
Charging icon:
18.4 V
Charging icon:
Battery full
Battery charging
progress icon
Battery capacity
percent rate
USB power
DC 12V IN icon
Battery channel
