HEDD BASS - HEDD Subwoofers Specifications

HEDD Subwoofers BASS 08 BASS 12
Woofer (honeycomb diagram) 8’’ (2’’ voice coil) 12’’ (2.5’’ voice coil)
Frequency response (-3 dB) 24 - 80 Hz 20 - 80 Hz
Upper frequency limit (var.) 40 - 120 Hz 40 - 120 Hz
LF range (-3 dB): normal / extended 24 / 19 Hz 20 / 16 Hz
Input analog / digital (AES) 2x / 1x XLR 2x / 1x XLR
Input impedance (balanced) 22 kΩ 22 kΩ
Input gain ± 12 dB ± 12 dB
Input sensitivity: 0 dB = 90 dB SPL/m -10 / -4 / 0 / +4 dB -10 / -4 / 0 / +4 dB
Output: AES “through” XLR XLR
HEDD Lineariser®, disengageable, delay 30 ms 30 ms
Phase switch 0 / 90 / 180 / 270° 0 / 90 / 180 / 270°
Satellite oset (analog out) ± 2m, in .5 m steps ± 2m, in .5 m steps
Frequency response (-3 dB) 24 - 80 Hz 20 - 80 Hz
Maximum SPL at 1 m (half space) 105 dB 115 dB
Power amplier / universal mains 110 - 240 V 300 W ICEpower 700W ICEpower
AD/DA Conversion 96 kHz / 32 Bit 96 kHz / 32 Bit
Cabinet with satin lacquer nish black black
Dimensions (H x W x D) 392 x 290 x 400 mm 595 x 380 x 610 mm
Weight 17 kg 32.1 kg
Warranty 2 years 2 years
HEDD Audio GmbH | Salzufer 13-14 | 10587 Berlin | Germany
www.hedd.audio | info@hedd.audio
Heinz Electrodynamic Designs
