7 – 8 HEIDENHAIN Technical Manual for Inverter Systems and Motors
7.2.1 Asynchronous Motors, QAN Series
Designation Rated power Rated speed ID Type of
power cable
a
QAN 104B – (page 7 – 146) 4.5 kW 1500 rpm 331 146-11 1
QAN 104C – (page 7 – 146) 7.5 kW 1500 rpm 331 147-11 1
QAN 104D – (page 7 – 146) 10.0 kW 1500 rpm 331 148-11 2
QAN 134B – (page 7 – 164) 12.0 kW 1500 rpm 331 149-11 2
QAN 134C – (page 7 – 164) 18.0 kW 1500 rpm 331 150-11 7
QAN 134D – (page 7 – 164) 22.0 kW 1250 rpm 331 151-11 7
QAN 164B – (page 7 – 170) 31.5 kW 1350 rpm 331 152-11 8
QAN 200L – (page 7 – 151)
with standard bearing
with spindle bearing
7.5 kW 1500 rpm
374 329-01
374 329-11
4
QAN 200M – (page 7 – 151)
with standard bearing
with spindle bearing
5.5 kW 1500 rpm
374 328-01
374 328-11
4
QAN 200U – (page 7 – 151)
with standard bearing
with spindle bearing
10.0 kW 1500 rpm
374 330-01
374 330-11
4
QAN 260L – (page 7 – 155)
with standard bearing
with spindle bearing
20.0 kW 1500 rpm
510 020-01
510 020-13
9
QAN 260M – (page 7 – 155)
with standard bearing
with spindle bearing
15.5 kW 1500 rpm
510 019-01
510 019-13
9
QAN 260U – (page 7 – 155)
with standard bearing
with spindle bearing
24.0 kW 1500 rpm
510 021-01
510 021-13
9
QAN 260W – (page 7 – 155)
with standard bearing
with spindle bearing
12.0 kW 750 rpm
510 022-01
510 022-13
5
QAN 320M – (page 7 – 160)
with standard bearing
with spindle bearing
32.0 kW 1500 rpm
513 302-01
513 302-13
10
QAN 320L – (page 7 – 160)
with standard bearing
with spindle bearing
40.0 kW 1500 rpm
577 484-01
577 484-13
10
1
QAN 320W – (page 7 – 160)
with standard bearing
with spindle bearing
18.0 kW 750 rpm
517 952-01
517 952-13
9
QAN 3L – (page 7 – 147) 7.5 kW 1500 rpm 316 007-31 4
QAN 3M – (page 7 – 147) 5.5 kW 1500 rpm 316 006-31 3
QAN 3U – (page 7 – 147) 10.0 kW 1500 rpm 316 008-31 5
QAN 4S – (page 7 – 168) 15.0 kW 1800 rpm 317 449-31 6
a. The specification for the QAN power cables can be found in the table in the section
“Power cables for HEIDENHAIN asynchronous motors” on page 14.
