April 2007 Power Connection of the HEIDENHAIN Motors 7 – 25

QSY 093B and

QSY 112 motors

The power connection of the HEIDENHAIN synchronous motors QSY 093B

and QSY 112 is made via an 11-pin flange socket.

Flange socket

(male)

11-pin

Assignment Connector

(female)

11-pin

Power cable Inverter

Terminal

3-pin

A U A Black 1 U

B V B Black 2 V

C W C Black 3 W

D PE GN/YL

F +24 V (brake) F Black 6 Intermediate

terminals

G 0 V (brake) Black 5 Intermediate

terminals

E, H, J, K Do not

assign

E, H, J, K Do not assign Do not assign

L Internal

shield

L Internal shield Intermediate

terminals
