7 – 246 HEIDENHAIN Technical Manual for Inverter Systems and Motors
Dimensions of
1FK7083-5AF71
Rotatable connections
Without brake With brake
¬ 130j6
58
¬ 32k6
217
88
42
55
13
3.5
22.5
¬ 130j6
58
¬ 32k6
268
115
42
55
13
3.5
22.5
90°
¬ 11
¬ 165
13.5
17.5
£ 155
£ 186
Connector for speed encoder Connector for power connection
51
R
¬ 28
R
76.5
¬ 28.2
270°
270°

HEIDENHAIN TNC 410 M Specifications

General

Control type	CNC
Power supply	24 V DC
Relative humidity	80% non-condensing
Interface	RS-232
Storage temperature	-20 to +70 °C
