Instruction manual CORDLESS 3
Illustr. 1
1 Proper Use
1.1 Overall View / Controls
Component Names
1.2 Intended Use
The clipping machine is exclusively intended for use on cattle and horses.
Other uses, in particular using the machine on people, are expressly prohibited.
Note
Danger of blockage! The machine must not be operated unless the blades are fitted.
1.3 Technical Data
Shearing Machine
Model Designation: CORDLESS
Motor Output:
RPM:
Dimensions (W/H/L): approx. 80 mm x 72 mm x 310 mm
Weight without battery: 840 g
Weight with battery: 1207 g
Max. Ambient Temperature: 0°C - 40°C
Max. Air Humidity: 10% - 90% (relative)
Noise Emission (L
pAm
): <70 dB(A) (DIN-45635-1/04.84 + BG-PAS 26)
Acceleration (a
vhw
): <4,6 m/sec
2
(EN-28662-1/01.93)
see rating plate
POS DESCRIPTION TOTAL
1 Clipper head case USV/HANDY/CORDLESS 1x
2 Driving carrier USV/HANDY/CORDLESS 1x
3 Crank spindle sleeve USV/HANDY/CORDLESS 1x
4 Crankshaft USV/HANDY/CORDLESS 1x
5 Crank drive block 1x
6 Cogwheel Z52 CORDLESS brown 1x
7 Tension screw USV/HANDY/CORDLESS 1x
8 Distance screw USV/HANDY/CORDLESS/DELTA1/PROGRESS 1x
9 Pressure plate 1x
10 Centering bush 2x
11 Pressure spring 1x
12 Laminated spring 2x
13 PH-screw M5 x 16 2x
14 Comb screw cattle/horse 2x
15 PT-screw Kombitorx KA40 x 16 2x
16 Circlip for shaft Ø6 1x
17 Socket head cap screw partially threaded M3 x 6 2x
18 Clipper head CORDLESS with blades 1x
19 Motor housing CORDLESS Heiniger grey 1x
20 Connection plate CORDLESS with overload protection 1x
POS DESCRIPTION TOTAL
21 Battery junction housing CORDLESS black 1x
22 Spring CORDLESS with brush 1x
23 Spring pin Ø3.5 x 22 1x
24 Switch CORDLESS with cover 1x
25 Motor CORDLESSwith cogwheel 1x
26 PH-screw M2.6 x 6 2x
27 PT-screw countersunk KA35 x 18 4x
28 NiCd battery CORDLESS7.2V / 2Ah Heiniger black 1x
29 Charger CORDLESS Heiniger 230V EURO 1x
29 Charger CORDLESS Heiniger 120V USA 1x
29 Charger CORDLESS Heiniger 230V AUS 1x
29 Charger CORDLESS Heiniger 230V GB 1x
29a Housing for charger CORDLESS complete 1x
29b Electronics for charger CORDLESSC 1x
29c Transformer for charger CORDLESS 240V 1x
29c Transformer for charger CORDLESS 120V 1x
29d Cable for charger CORDLESS EURO 1x
29d Cable for charger CORDLESS USA 1x
Converter EURO/GB plug 1x
