Pag.4
1. Instructions for using the Hi-fire.
1.1 Control knobs and other functions of gas regulator block (see page 13 diagram 2).
• Pilot light ignition knob (A1) on gas regulator block
• Manual control gas fire (A2) on gas regulator block
This gas regulator is fitted with a manual operating system and a radiographic one.
Ensure that the batteries are in place in both the remote control and the battery holder/signal receiver (see page 7
paragraph 2.4). The remote control signal has a maximum range of approximately 5 meters.
1.2 Operation Lighting Procedure (see page 13 diagram 2)
1. Turn knob (A1) slightly left towards the ignition position until reaching stop, press down and hold
for five seconds (only pilot gas flows).
2. Continue pressing down knob (A1) while turning further left to activate piezo, continue to hold down
for 10 seconds after pilot burner has been lit. If pilot does not light, steps 1 and 2 can be repeated immedi-
ately.
3. Upon lighting, release knob and turn further left to position . Pilot gas flows and main gas flows in
accordance to the temperature setting knob (A2).
1.3 Adjusting the flame height
To turn the fire on and/or to increase the flame height, press button B6 of the remote handset. Continue pressing
until the desired flame height is obtained. Press and hold button B7 to reverse the procedure.
The motorized valve is equipped with a slip clutch, allowing manual adjustment of main gas by turning knob
(A2).
1.4 Shut-off Procedure
1. Turn knob (A) right until reaching stop . In this position only pilot gas flows.
2. To shut off the valve completely, press down slightly and continue turning right from pilot position to the
OFF ? position. The safety interlock prevents re-ignition of the pilot flame until the thermocouple has
cooled down sufficiently (elapsed time will vary based on thermocouple type).
3. Switching off the remote is not necessary.
1.5 Remote control with thermostat and timer. (see page 13 diagram 2-B)
Set the display
• After connecting the battery or by simultaneously pressing the buttons (B-4) and (B-5), the display flashes.
You are in set mode.
• From set mode, press button (B-4) to switch from °F ( and 12 hour clock) to °C ( and 24 hour clock) or
vice versa.
• The display will automatically return to manual mode after some time, but you may immediately return to
manual by depressing the button (B-5) .
Set the current time
• After connecting the battery or by simultaneously pressing the buttons (B-4) and (B-5), the display flashes.
You are in set mode.
• From set mode, press button (B-6) to set the hour and button (B-7) to set the minute
• Wait or press Timer to return to manual mode.
Programming the desired set temperature
• Press button (B-4) until the display flashes.
• Press button (B-6) or button (B-7) to set the desired temperature
