HELIX Broadcaster 100 User Manual

Helix Broadcaster 100 Touch Screen User Guide CHAPTER 1: System Setup
3
Tip: Depress the power switch approximately five seconds to turn the unit off.
Press the power switch briefly or tap the screen if the screen times out.
Setting the WAN Address
The back of the Helix Broadcaster 100 lists the default IP address for the WAN port. If you
must change the WAN IP address or enable DHCP before placing the Helix Broadcaster
machine on your network, follow the procedures below.
Tip: If you can place the machine on your network without changing the
default IP address at first, you can use the machine immediately and log in to
the browser or SSH interface as described on page 5. You can then modify
network settings, such as setting the address for both the primary and
secondary Ethernet ports.
Network Setup Screen
Do the following to display the Network Setup screen where you can enable DHCP or set the
static IP address.
➤ To display the network setup screen:
1. Tap System on the Appliance Manager menu.
System Category on Appliance Manager Screen
2. Tap Network on the System Setup menu that appears.
Network Category on System Setup Screen
3. The Network Setup screen appears. You can then configure DHCP or set a static address as
described next.
DHCP Lookup
If your network uses DHCP to assign IP addresses, set Helix Broadcaster to query the network
and receive an IP address.
