- 7 -
2/ BEFORE YOUR BEGIN
IMPORTANT: Read all instructions carefully. Assemble the Helix in accordance with the steps in the manual. All
tools required for assembly are included with your Helix. Lay out all parts on the floor. Make sure that you have all
the parts listed below before beginning assembly. In case of a discrepancy, please contact our Customer Service
Department at the email address or customer service number listed on the back page of this Owner’s Manual.
PRE-ASSEMBLY CHECK LIST
Note:
Some parts may be factory pre-assembled.
Item # Description Qty
1 LEFT AND RIGHT FRAME LEGS 2
2 TRANSPORT PLATE ASSEMBLY 2
3 PEDAL FRAME AND COVERS 2
4 MAIN FRAME 1
5 RUBBER GASKET FOR UPRIGHT 1
6 COMPUTER 1
7. CENTER UPRIGHT TUBE 1
8. HANDLEBAR 1
9. TOP COVER 1
10. WATER BOTTLE HOLDER SCREWS 2
Item #Description Qty
11. PEDAL FRAME BOLTS 6
12. COMPUTER BOLTS 4
13. ALLEN HEAD UPRIGHT BOLTS 4
14. HEX HEAD UPRIGHT BOLTS 2
15. BOLTS 4
16. ASSEMBLY TOOLS 5
17. WATER BOTTLE HOLDER 1
18. ELECTRICAL PLUG 1
19. TRANSPORT PLATE BOLTS 2
20. HANDLEBAR NUTS 4
helix manuals_Helix H1000 - lowres 26/06/2013 13:11 Page 7
