Hellenbrand TS Series - Page 4

RATED CAPACITY
RESIN PIPE SIZE LOW SALT MEDIUM SALT HIGH SALT FLOW RATE PEAK BWK
MODEL CU.FT. (INCHES) GRAINS/LBS GRAINS/LBS GRAINS/LBS CONT. 15 PSI 25 PSI GPM
TS-30-1 1.0 1" 19,000/6 28,000/10 32,000/15 15.0 20.0 2.0
TS-45-1 1.5 1" 28,500/9 42,000/15 48,000/22.5 16.0 22.0 2.4
TS-60-1 2.0 1" 38,000/12 56,000/20 64,000/30 20.0 26.0 3.5
TS-60-1.5 2.0 1.5" 38,000/12 56,000/20 64,000/30 31.4 43.0 3.5
TS-90-1 3.0 1" 57,000/18 84,000/30 96,000/45 19.0 26.0 4.0
TS-90-1.5 3.0 1.5" 57,000/18 84,000/30 96,000/45 30.2 41.7 4.0
TS-120-1 4.0 1" 76,000/24 112,000/40 128,000/60 20.0 27.0 5.0
TS-120-1.5 4.0 1.5" 76,000/24 112,000/40 128,000/60 33.2 45.2 5.0
TS-150-18-1 5.0 1" 95,000/30 140,000/50 160,000/75 21.0 28.0 7.0
TS-150-18-1.5 5.0 1.5" 95,000/30 140,000/50 160,000/75 36.0 49.0 7.0
TS-150-22-1 5.0 1" 95,000/30 140,000/50 160,000/75 22.0 29.0 9.0
TS-150-22-1.5 5.0 1.5" 95,000/30 140,000/50 160,000/75 41.5 55.3 9.0
TS-180-18-1 6.0 1" 114,000/36 168,000/60 192,000/90 20.0 27.0 7.0
TS-180-18-1.5 6.0 1.5" 114,000/36 168,000/60 192,000/90 34.0 47.0 7.0
TS-180-22-1 6.0 1" 114,000/36 168,000/60 192,000/90 21.0 28.0 9.0
TS-180-22-1.5 6.0 1.5" 114,000/36 168,000/60 192,000/90 40.0 53.6 9.0
TS-210-1 7.0 1" 133,000/42 196,000/70 224,000/105 20.0 27.0 9.0
TS-210-1.5 7.0 1.5" 133,000/42 196,000/70 224,000/105 38.5 51.9 9.0
TS-240-1.5 8.0 1.5" 152,000/48 224,000/80 256,000/120 42.0 56.0 12.0
TS-270-1.5 9.0 1.5" 171,000/54 252,000/90 288,000/135 41.0 54.8 12.0
TS-300-1.5 10.0 1.5" 200,000/60 280,000/100 320,000/150 40.5 54.0 12.0
OPERATING CONDITIONS
1. Water Pressure 30 - 100 psi.
2. Water temperature is not to exceed 110 F and cannot be subject to freezing conditions.
3. Limit of 2 ppm of Ferrous Iron. Add 3 grains of hardness per ppm of iron when sizing.
Product improvement designs are subject to change without notice.
4. Electrical requirements: 115Vac - 15 Amp Circuit.
TS-1.5" INLET OUTLET
SERIES HEIGHT WIDTH TWIN HEIGHT HEIGHT
MODEL (INCHES) (INCHES) (INCHES) (INCHES) (INCHES)
TS-60 63 37 56 56.5 57.5
TS-90 73 38 58 67.5 68.5
TS-120 73 46 68 67.5 68.5
TS-150
-180-18 76 46 68 69.0 70.5
TS-150
-210-22 75.5 52 80 65.5 70.5
TS-240 83 54 84 65.5 78.0
TS-270-300 83 54 84 73.5 78.0
TS Physical Specications
TS Capacity
TS-1.5” Series Dimensions
